| TC-3500S
Floor stand model |
TC-3500
Desktop model |
|
| Dimensions
(WxDxH) |
340(W)x325(D)x895(H) mm | 340(W)x325(D)x350(H) mm |
| Weight | 37 (KG) | 26 (KG) |
| Countable
Banknote Size |
Width 45-100 mm
Length 100-240 mm Thickness 0.05-0.2 mm |
|
| Counting Speed | 1600, 2000, 2400 pcs/min | |
| Counting Mode | Free, Manual, Check, Batch, ADD | |
| Display | Touch Panel
Count/Batch – 3 Digits ADD – 5 Digits |
|
| Hopper Capacity | Approx. 200 – 250 notes | |
| Optional Device | UV Detection
OK Stamp LED External Display |
|
| Power Consumption | 330W | |
TC-3500(S)
TC-3500(S) Series is an advanced vacuum banknote counter designed for fast and efficient verification of strapped banknotes. Featuring variable counting speeds, optional UV counterfeit detection, and an anti-noise shutter, it delivers reliable performance while improving both operating flexibility and user comfort.
Features:
- Check Mode: Verifies a Known Quantity (100pcs) in a Bundle
- Preset Mode: Counting for Batched Number
- Manual Mode: Start Counting by Manual
- Batch Mode: 10,20,25,50,100 and up to the user needs (from1-999)
- ADD Mode: Several Counts can be Totaled and Displayed
- UV-Detection (Optional): Detecting & Sorting out the Counterfeit Banknotes
- Shutter: Automatic Dust-Proof and Anti-Noise Shutter
